Setup

Generate RSA key pair

openssl genrsa -out private.pem 2048
openssl rsa -pubout -in private.pem -out public.pem

1. Go to Bank Registration page, input your bank’s name, your email and password.
2. Go to your profile details tab and save your app_id and app_secret.
3. Set the url of your connector
4. Generate public/private key pair
5. Go to your profile security tab and paste your public key there.

API Endpoints

All the incoming requests are encrypted with the public key you pasted before in your profile.

The following endpoints MUST be implemented in your connector:

• /api/priora/v1/tokens/create
• /api/priora/v1/tokens/confirm
• /api/priora/v1/tokens/revoke
• /api/priora/v1/payments/create
• /api/priora/v1/payments/confirm
• /api/priora/v1/kyc
• /api/priora/v1/transactions
• /api/priora/v1/accounts

Enrollment Flow

Request from Priora

Request payload

{
  "data":
    {
      "algorithm": "AES-256-CBC",
      "key": "encr_key",
      "iv": "iv",
      "data": "encrypted_data"
    }
}

Request headers

{
  "Signature": "priora_signature"
  "Expires-At": 1496159522
}

Priora sends a request to https://your.connector.com/api/priora/v1/tokens/create

Validate

Connector has to check signature using priora’s public key.

-----BEGIN PUBLIC KEY-----
MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQC95VEwkM1qHxgEdkTlX9TOxK70
REPQ/4lAWZkq6qnfzEEMSaeSwnv1aZnKXe82DEkaDx4qYyhybetnhcMaNYgrf4pp
Gl4pHyrko+J4uVeu0oUVvAdaOWtnzcpkIvPZs4f0e3se4H7MJ4XoOROnYKTAKaGh
03ipCDa4KH//7ZtHHwIDAQAB
-----END PUBLIC KEY-----

Connector should validate whether request is not expired and request’s signature.

Decrypt original request

Decrypted Request

{
  "data": {
    "session_secret": "STk_HeFrzSCoK4BOkfpbOkXKXyQiR2Hy7ZarHNzVuGc",
    "original_request": {
      "signature": "authenticator_request_signature",
      "expires_at": "1496159522",
      "method": "POST",
      "original_url": "https://priora.saltedge.com/api/authenticator/v1/tokens",

      "body_content": {
        "data": {
          "provider_code": "demobank",
          "credentials": {
            "login": "test",
            "password": "test"
          },
          "scopes": [
            "authenticator"
          ],
          "public_key": "-----BEGIN PUBLIC KEY-----
          MIIBIjANtznaA+L
          n1+pO9B7hRJF32/cpoVdZvYPkduv+
          dWpeAmKiJLs1/z6vbqyvm5D03cqwgi3e7v4
          WQIDAQAB
          -----END PUBLIC KEY-----"
        }
      }
    }
  }
}

Original request is encrypted on Priora’s side and therefore must be decrypted first, which will result into Decrypted Request.

Validate original request

Signature from the original request should also be validated using authenticator’s app public key (later will be requested from eIDAS).

Token creation

Token Instructions

  {
    "extra": {
      "instructions": "Confirm your authotization."
    },
    "session_expires_at": "2017-06-01T12:37:33.000Z",
    "name": "instructions",
    "session_secret": "STk_HeFrzSCoK4BOkfpbOkXKXyQiR2Hy7ZarHNzVuGc"
  }

Next connector validates user credentials and if they are correct create a Token in its database. Then connector should send signed POST request to /api/connectors/v1/sessions/update on Priora with Token Instructions.

Token confirmation

Token Confirmation

  {
    "user_id": "1",
    "provider_token": "generated token string",
    "provider_token_expires_at": "expires_at for generated token",
    "session_secret": "STk_HeFrzSCoK4BOkfpbOkXKXyQiR2Hy7ZarHNzVuGc"
  }

Token has unconfirmed status until user confirms it using channel different from Priora. When user confirms a token, connector should send signed POST request to /api/connectors/v1/sessions/success on Priora with Token Confirmation.

AISP Linking Flow

Request from Priora

Request payload

{
  "data":
    {
      "algorithm": "AES-256-CBC",
      "key": "encr_key",
      "iv": "iv",
      "data": "encrypted_data"
    }
}

Request headers

{
  "Signature": "priora_signature"
  "Expires-At": 1496159522
}

Priora sends a request to https://your.connector.com/api/priora/v1/tokens/create

Validate

Connector has to check signature using priora’s public key.

-----BEGIN PUBLIC KEY-----
MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQC95VEwkM1qHxgEdkTlX9TOxK70
REPQ/4lAWZkq6qnfzEEMSaeSwnv1aZnKXe82DEkaDx4qYyhybetnhcMaNYgrf4pp
Gl4pHyrko+J4uVeu0oUVvAdaOWtnzcpkIvPZs4f0e3se4H7MJ4XoOROnYKTAKaGh
03ipCDa4KH//7ZtHHwIDAQAB
-----END PUBLIC KEY-----

Connector should validate whether request is not expired and request’s signature.

Decrypt original request

Decrypted Request

{
  "data": {
    "session_secret": "STk_HeFrzSCoK4BOkfpbOkXKXyQiR2Hy7ZarHNzVuGc",
    "original_request": {
      "signature": "authenticator_request_signature",
      "expires_at": "1496159522",
      "method": "POST",
      "original_url": "https://priora.saltedge.com/api/authenticator/v1/tokens",
      "body_content": {
        "data": {
          "provider_code": "demobank",
          "credentials": {
            "login": "test",
            "password": "test"
          },
          "scopes": [
            "accounts"
          ]
        }
      }
    }
  }
}

Original request is encrypted on Priora’s side and therefore must be decrypted first, which will result into Decrypted Request.

Validate original request

Signature from the original request should also be validated using authenticator’s app public key (later will be requested from eIDAS).

Waiting for confirmation

Confirmation Await

  {
    "name": "waiting_confirmation_code",
    "confirmations": [
      {
        "provider_code": "demobank",
        "token": "token of the linked authenticator belonging to this user",
        "code": "confirmation code encrypted with linked authenticator's public key"
      }
    ]
  }

Token has unconfirmed status until user confirms it using channel different from Priora. When user confirms a token, connector should send signed POST request to /api/connectors/v1/sessions/success on Priora with Confirmation Await.

AISP Data Extraction

Know Your Customer

Headers

{
  "Signature": "priora_signature"
  "Expires-At": 1496159522
}

GET request to https://your.connector.com/api/priora/v1/kyc?token=token-of-the-linked-aisp.

Accounts

Headers

{
  "Signature": "priora_signature"
  "Expires-At": 1496159522
}

GETrequest to https://your.connector.com/api/priora/v1/accounts?token=token-of-the-linked-aisp.

Transactions

Headers

{
  "Signature": "priora_signature"
  "Expires-At": 1496159522
}

GET request to https://your.connector.com/api/priora/v1/transactions?token=token-of-the-linked-aisp&account-id=1.

PISP Linking Flow

Request from Priora

Request payload

{
  "data":
    {
      "algorithm": "AES-256-CBC",
      "key": "encr_key",
      "iv": "iv",
      "data": "encrypted_data"
    }
}

Request headers

{
  "Signature": "priora_signature"
  "Expires-At": 1496159522
}

Priora sends a request to https://your.connector.com/api/priora/v1/tokens/create

Validate

Connector has to check signature using priora’s public key.

-----BEGIN PUBLIC KEY-----
MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQC95VEwkM1qHxgEdkTlX9TOxK70
REPQ/4lAWZkq6qnfzEEMSaeSwnv1aZnKXe82DEkaDx4qYyhybetnhcMaNYgrf4pp
Gl4pHyrko+J4uVeu0oUVvAdaOWtnzcpkIvPZs4f0e3se4H7MJ4XoOROnYKTAKaGh
03ipCDa4KH//7ZtHHwIDAQAB
-----END PUBLIC KEY-----

Connector should validate whether request is not expired and request’s signature.

Decrypt original request

Decrypted Request

{
  "data": {
    "session_secret": "STk_HeFrzSCoK4BOkfpbOkXKXyQiR2Hy7ZarHNzVuGc",
    "original_request": {
      "signature": "authenticator_request_signature",
      "expires_at": "1496159522",
      "method": "POST",
      "original_url": "https://priora.saltedge.com/api/authenticator/v1/tokens",
      "body_content": {
        "data": {
          "provider_code": "demobank",
          "credentials": {
            "login": "test",
            "password": "test"
          },
          "scopes": [
            "payments"
          ]
        }
      }
    }
  }
}

Original request is encrypted on Priora’s side and therefore must be decrypted first, which will result into Decrypted Request.

Validate original request

Signature from the original request should also be validated using authenticator’s app public key (later will be requested from eIDAS).

Waiting for confirmation

Confirmation Await

  {
    "name": "waiting_confirmation_code",
    "confirmations": [
      {
        "provider_code": "demobank",
        "token": "token of the linked authenticator belonging to this user",
        "code": "confirmation code encrypted with linked authenticator's public key"
      }
    ]
  }

Token has unconfirmed status until user confirms it using channel different from Priora. When user confirms a token, connector should send signed POST request to /api/connectors/v1/sessions/success on Priora with Confirmation Await.

PISP Payment Flow

Payment creation

Payload

{
  "fees": {
    "internal": {
      "amount": 0.0025,
      "currency_code": "EUR",
      "description": "Priora service fee",
      "code": "priora_service_fee"
    }
  },
  "session_secret": "F6567XbVjHsr0Z1-1bRct6V5rvYDmQZA0YoKTpNIpiY",
  "token": "186WKRXPdcSf_m-SimSG3AmjcnVlbbDVELshWD6qDf4",
  "payment_id": 95,
  "original_request": {
    "data": "V7dVMRr0MRBgS5hMRXCBpo3IXGylcq4ceAcrN3DNVLpn=="
  }
}

Headers

{
  "Signature": "priora_signature"
  "Expires-At": 1496159558
}

POST request to https://your.connector.com/api/priora/v1/payments/create.

Data within original_request is encrypted using connector’s public key and therefore should be decrypted. Result will be similar to Decrypted original_request.

Decrypted original_request

{
  "signature": "BaCt2sr67XbRV/IuKxhjaApByDMQ10THF1zgY9tYCFzg==",
  "expires_at": "1496232936",
  "method": "POST",
  "original_url": "http://priora.saltedge.com/api/pisp/v1/payments",
  "body_content": {
    "data": {
      "provider_code": "demobank",
      "amount": "101.0",
      "description": "Test transaction",
      "currency_code": "USD",
      "merchant": {
        "name": "Amazon"
      },
      "type": "transfer",
      "source": {
        "iban": "DE12345678123456781233"
      },
      "destination": {
        "iban": "DE12345678123456781232"
      }
    }
  }
}

Payment confirmation

Payload

{
  "token": "186WKRXPdcSf_m-SimSG3AmjcnVlbbDVELshWD6qDf4",
  "payment_id": 95,
  "connector_payment_id": "8",
  "original_request": {
    "data": "JhCV7dVMeXq4x7XIMirhI3hrbOdKFiYhgIEja13anhYRtMz3=="
  }
}

Headers

{
  "Signature": "priora_signature"
  "Expires-At": 1496159558
}

POST request to https://your.connector.com/api/priora/v1/payments/confirm.

Connector has to decrypt using its private key original_request‘s data, which will result into something similar to Decrypted original_request.

Decrypted original_request

{
  "signature": "UGHqO2SgruBAARN/L7XoEBpo3IXGylcq4ceAcrN3DNVLpnam8p3zjUQ==",
  "expires_at": "1496232946",
  "method": "PUT",
  "original_url": "http://priora.saltedge.com/api/pisp/v1/sessions/confirm",
  "body_content": {
    "data": {
      "secret": "F6567XbVjHsr0Z1-1bRct6V5rvYDmQZA0YoKTpNIpiY",
      "confirmation_code": "0ad484"
    }
  }
}

Current Database Schema

Accounts

Column	Type	Constraints	Defaults
user_id	integer
name	string
number	string
currency_code	string
sort_code	string
iban	string
nature	string
payment_account	boolean
balance	decimal	precision: 30, scale: 10, null: false
available_amount	decimal	precision: 30, scale: 10, null: false
extra	jsonb		{ }
created_at	datetime	null: false
updated_at	datetime	null: false

Payments

Column	Type	Constraints	Defaults
token_id	integer	null: false
user_id	integer	null: false
account_id	integer	null: false
priora_payment_id	integer	null: false
total	decimal	null: false
amount	decimal	null: false
provider_code	string	null: false
description	string	null: false
currency_code	string	null: false
status	string	null: false
type	string	null: false
confirmation_code	string
fees	jsonb		{ }
extra	jsonb		{ }
merchant	jsonb		{ }
source	jsonb		{ }
destination	jsonb		{ }
created_at	datetime	null: false
updated_at	datetime	null: false

Tokens

Column	Type	Constraints	Defaults
token	string	null: false
expires_at	datetime	null: false
session_secret	string	null: false
public_key	text	null: false
scopes	text[]	null: false	[ ]
provider_code	string	null: false
confirmation_code	string
status	string	null: false	“unconfirmed”
extra	jsonb		{ }
user_id	integer
created_at	datetime	null: false
updated_at	datetime	null: false

Transactions

Column	Type	Constraints	Defaults
account_id	integer	null: false
currency_code	string	null: false
amount	decimal	precision: 30, scale: 10, null: false
description	string	null: false, limit: 4000
made_on	date	null: false
status	string	null: false	“posted”
category	string	null: false	“uncategorized”
extra	jsonb
created_at	datetime	null: false
updated_at	datetime	null: false

Users

Column	Type	Constraints	Defaults
login	string	null: false	“”
email	string	null: false	“”
encrypted_password	string	null: false	“”
kyc	jsonb
created_at	datetime	null: false
updated_at	datetime	null: false
